€93.50*
Product number:
A 161E PDF-14
The standard was published in May 2018, based on the German edition of March 2014 in the corrected version of October 2017.
This standard applies to the structural calculation of pipes with a circular cross-section which are installed according to the pipe jacking method in a straight or bending direction in non-cohesive or cohesive soils (loose soils as according to DIN 18319) with static force in accordance with Standard DWA-A 125/DVGW GW 304. For jacking in solid rock, either wholly or in part, there is no standard solution in this regard, instead, special considerations are to be made; for example application of smaller bearing angles and earth load over the pipe crest. These calculation approaches and material characteristics are based on the pipe materials as per Annex A of this standard. This standard can analogously be applied to pipes driven with dynamic energy. Unless otherwise mentioned in this standard it also applies to pipe jacking using related methods with the appropriate adjustments. For pipes installed within a jacking path in an open-cut method of construction in shafts or connecting paths, Standard ATV-DVWK-A 127 applies.
| Ausgabe: | Mai 2018 |
|---|---|
| Format: | A4 |
| Gruppe: | Drain and Sewer Systems |
| ISBN: | 978-3-96862-270-5 |
| Kategorie: | Rules and Standards |
| Seitenzahl: | 99 |
| Sprache: | English |
| Verlag: | DWA |
Preview "DWA-A 161E - Static calculation of Jacking Pipes - March 2014, corrected version March 2021"
